LEGACY CARS
CMT13
Engine
80HP @10,000 RPM Honda CBR600 RR with custom intake and exhaust.
Drivetrain
Sequential 6-speed gearbox, chain drive with Drexler Limited Slip Differential.
Chassis
Steel spaceframe.
Suspension
Double unequal length wishbone, pull-rod actuated, Ohlins dampers, custom aluminium CNC uprights.
Brakes
Custom stainless steel brake discs with Wilwood calipers.
Wheels and Tyres
Custom multi-piece lightweight aluminium rims with Hoosier 20.5x7-13.
DAQ
ViPEC V44 and wideband O2 sensor for driver feedback.
Front Wing
Semi Sprung, 2 elements plus mainplane, adjustable angle of attack.
Rear Wing
Fully unsprung, 2 elements plus mainplane.
Total Downforce
1000N.
Total Drag
500N (at 60 km/h).
CMT11-12
Engine
80HP @10,000 RPM Honda CBR600 RR with custom intake and exhaust.
Drivetrain
Sequential 6-speed gearbox, chain drive with Torsen differential.
Chassis
Steel spaceframe.
Suspension
Double unequal length wishbone, pull-rod actuated, Ohlins dampers, custom aluminium CNC uprights.
Brakes
Custom stainless steel brake discs with Wilwood calipers.
Wheels and Tyres
Custom multi-piece lightweight aluminium rims with Hoosier 20.5x7-13.
DAQ
ViPEC V44 and wideband O2 sensor for driver feedback.
CMT09-10
Engine
80HP @10,000 RPM Honda CBR600 RR with custom intake and exhaust.
Drivetrain
Sequential 6-speed gearbox, chain drive with Torsen differential.
Chassis
Steel spaceframe.
Suspension
Double unequal length wishbone, pull-rod actuated, Ohlins dampers, custom aluminium CNC uprights.
Brakes
Custom stainless steel brake discs with Wilwood calipers.
Wheels and Tyres
Custom multi-piece lightweight aluminium rims with Hoosier 20.5x7-13.
DAQ
ViPEC V44 and wideband O2 sensor for driver feedback.
CMT08
Engine
75HP @10,000 RPM Honda CBR600 F4i with custom intake and exhaust.
Drivetrain
Sequential 6-speed gearbox, chain drive with Torsen differential.
Chassis
Steel spaceframe.
Suspension
Double unequal length wishbone, pull-rod actuated, FoxShox dampers, custom ChroMoly box-section uprights.
Brakes
Custom stainless steel brake discs with Wilwood calipers.
Wheels and Tyres
Custom lightweight aluminium rims with Hoosier 20.5x7-13.
DAQ
Autronic SM4 ECU, DL1 data acquisition and wideband O2 sensor for driver feedback.
CMT05-06
Engine
75HP Honda CBR600 F4i with custom intake and exhaust.
Drivetrain
Sequential 6-speed gearbox, chain drive with Torsen differential.
Chassis
Steel spaceframe.
Suspension
Double unequal length wishbone, pull-rod actuated, FoxShox dampers, custom aluminium CNC uprights.
Brakes
Custom stainless steel brake discs with Wilwood calipers.
Wheels and Tyres
Formula Ford standard wheels with Hoosier 20.5x6-13.
DAQ
Autronic SM4 ECU, DL1 data acquisition and wideband O2 sensor for driver feedback.
CMT03
Engine
Suzuki GSX-R 600cc.
Drivetrain
Sequential 6-speed gearbox, chain drive with viscous differential.
Chassis
Steel spaceframe.
Suspension
Double unequal length wishbone, pull-rod actuated.
Wheels and Tyres
Formula Ford standard wheels with Hoosier 20.5x6-13.
