CMT18
Placements
Overall: 6TH
Acceleration: 4TH
Auto Cross: 2ND
Endurance: 9TH
Skid Pad: 6TH
Business: 1ST
Cost Report: 10TH
Design: 6TH
Efficiency: 10TH
Powertrain
Cooling
PWR custom built radiator.
Drivetrain
Continuously Variable Transmission (CVT) with Drexler Limited Slip Differential.
Engine
Yamaha Genesis 80fi.
Exhaust
2-1 ceramic coated with custom muffler.
Fuel System
6.4L tank with Goss GE044 pump.
Oil System
Dry sump.
Intake
Carbon plenum with 3D printed throttle body.
Aerodynamics
Bodywork
1 piece carbon construction, resin infusion layup.
Front Wing
Semi sprung, 3 element plus mainplane, foam core.
Rear Wing
Unsprung, 4 element, Foam Core.
Total Downforce
438N.
Total Downforce
223N (at 60 km/h).
Undertray
Single piece carbon construction, Seperate side-pod floors.
The Car
Electrical & Driver Interface
Battery
4 cell Lithium Iron Phosphate (LiFePO4) 15Ah.
DAQ
WiFi, GPS, and 3-axis accelerometer.
Dash
Custom RGB dashboard with CAN integration.
Loom
Military specification wire, concentric twisted, heat, chemical, and abrasion resistant.
Pedal Box
Adjustable IGUS dual rail, aluminium pedals and baseplate.
Power Electronics
300A capable power electronics.
Seat
Carbon construction, external headrest.
Steering Column
Double UJ, rack and pinion.
Vehicle Dynamics
Brakes
Front/Rear - Wilwood - GP200.
Master cylinder - Tilton 78-Series.
Chassis
Chromoly Spaceframe.
Dampers
Ohlins TTX-25.
Suspension
Direct Acting, Double Wishbone.
Tyres
Hoosier 18x7.5-10 R25B.
Unsprung
Machined aluminium uprights, spindles, and wheel centres.
Swaybars
Adjustable front and rear.
